ULTRA GREEN™ Series

Broan® ULTRA GREEN™ 110 CFM Humidity Sensing Ventilation Fan, <0.3 Sones; ENERGY STAR® Certified

The Broan® XB110H ULTRA GREEN™ Humidity Sensing Fan, ENERGY STAR® Certified, delivers premium performance for today's demanding requirements. 110 CFM of premium ventilation with ULTRASilent™ technology operates at the lowest sound rating achievable, less than 0.3 sones. The ULTRASense™ technology reacts to a rise in humidity, meaning you no longer have to remember to turn on the fan when you shower. The ULTRASmart DC motor and control technology provides energy efficiency almost 10 times greater than ENERGY STAR® requirements. With ULTRAQuick™ installation technology the XB110H provides the fastest, easiest, and most universal installation in remodel, retrofit, and new construction.


Model:

XB110H

Features

  • 110 CFM, Effective ventilation to remove moisture and reduce the risk of mold or mildew in most full baths
  • <0.3 Sones for Ultra quiet performance, you might not notice it's on
  • Sensaire™ humidity sensing technology, senses humidity up to 4X faster than the competition
  • ULTRAQuick™ Installation Technology uses an exclusive telescoping mounting frame with pre-installed screws
  • Snap-in housing, snap-in blower, and an inside-out mounting duct connector for the fastest, easiest, most universal installation
  • Mounting Frame fits any type of joist, I-Joist or truss construction for a "no guesswork" instllation to make the work fast and easy
  • ENERGY STAR® certified ventilation fan
  • UL listed for use over tubs/showers with GFCI circuit
  • Powerful enough for rooms up to 100 sq. ft.
  • Brighter white grilles blend in to match most common ceiling paint
  • Corrosion resistant galvanized steel housing stands up to moisture
  • Brushless DC electronically controlled digital motor is 3X more efficient than standard AC powered ventilation

Suggested Installation Accessories

Broan-NuTone® Steel Roof Cap for 6-Inch Round Duct with Backdraft Damper and Bird Screen, Black

Broan-NuTone® Steel Roof Cap for 6-Inch Round Duct with Backdraft Damper and Bird Screen, Black

Model:

634M

Broan-NuTone® Wall Cap, Steel, Black, 6-Inch Round Duct

Broan-NuTone® Wall Cap, Steel, Black, 6-Inch Round Duct

Model:

843BL

Flex Duct 6-Inch Insulated (25 ft.)

Flex Duct 6-Inch Insulated (25 ft.)

Model:

DT6W

Broan-NuTone® Occupancy Sensor, White

Broan-NuTone® Occupancy Sensor, White

Model:

MS100W

  • Specs
  • Downloads

print

CFM 110
Color Finish
Duct Size 6
ENERGY STAR® Certified Yes
Grille Length 13.125
Grille Width 14
Housing Dimensions 10-1/2" x 11-3/8" x 7-5/8"
UL Listed Yes
Grille Finish White
Humidity Sensing Yes
Motion Sensing No
Motor Engineered For Continuous Operation Yes
Night Light No
Radiation Damper Available Yes
Room Side Installation Yes
UL Listed for use over bathtubs or showers when connected to a GFCI circuit Yes
Heater Wattage 0
Recommended Room Size (Sq Ft) 105
Rated Amps 0.4
Voltage 120
Can Be Used To Comply With Title 24 Yes
Minimum Construction Space Required 2" x 8"
Manufacturer Warranty 3 Years
High Efficiency Luminaire No
