Broan® 20-1/2-Inch Custom Range Hood Power Pack, Silver Finish, 250 CFM

 Write a review Questions & Answers

NuTone Custom Power Module NSPM250 is a fully integrated range hood system with a 250 CFM fan designed to fit flush with the bottom of a cabinet or custom hood installation. Select this silver-finished blower with multi-speed control to provide quiet, effective performance. Incandescent lighting complements the beauty of a fully enclosed bottom containing dishwasher-safe filters to make cleaning easy. Designed to be used with custom liners (not included) in 30 in. and 36 in., "B" or "T" design.

Model:

NSPM250

Features

  • 6-7/8 in. round duct with vertical discharge provides efficient operation
  • Includes a built-in adapter for 7 in. round duct
  • Dishwasher-safe aluminum mesh filter helps ensures operation at the unit's highest capture level
  • Uses two 40-Watt candelabra bulbs for adequate cooktop lighting (sold separately)
  • Durable, powder coated silver finish has a professional appearance
  • Fully enclosed bottom allows for easy cleaning
  • UL and cUL listed, HVI 2100 certified for your safety, protection
  • One year limited warranty
  • Specs
  • Downloads

print

Filter Type Aluminum
Heat Sentry™ No
HVI Certified Yes
Lighting Type Incandescent
UL Listed Yes
ADA Compliance Yes
Damper Included Yes
ENERGY STAR® Certified No
Light Bulbs Included No
Light Levels 1
Nightlight Or Nighlight Setting No
Ductless Recirculation Capable No
Ductless Filter Or Kit Included No
Remote Operation Capable No
Speed Levels 2
Switch Control Type Capacitive Touch
Rated Voltage 120
Boost Mode No
Color Finish
Rated Amps 2.1
Product Height 2.5
Product Width 20-1/2"
Built-In Timer No
CFM 250
Diameter 7" Round
Vent Type Ducted & Ductless
Manufacturer Warranty 1 year
Specification Sheet
Installation Guide
ADA Wiring Instructions
