EZFit™ Series Ventilation Fans

NuTone®80 CFM Ventilation Fan, 1.1 Sones; ENERGY STAR Certified

Every feature of the NuTone® EZ80N EZFit Ventilation Fan is carefully devised for easy installation from the room side, without having to go into the attic. Pulling air efficiently at 80 CFM, this ENERGY STAR®-certified fan operates at a super-quiet sound level of 1.0 sone for a peaceful environment. Boasting a white polymeric grille that blends seamlessly with most decor, this bathroom vent fan installs directly to the ceiling material or to ceiling joists or trusses. It can be placed safely over a bathtub or shower if connected in a GFCI branch circuit.



  • Specs
  • Downloads
  • Videos


CFM 80
Color Finish
Duct Size 4
ENERGY STAR® certified Yes
Grille Length 14.5
Grille Width 13
Housing Dimensions 12" x 10-1/2" x 5"
Sound Level (Sones) 1.1
UL Listed No
Grille Finish White
Humidity Sensing No
Motion Sensing No
Motor Engineered For Continuous Operation No
Night Light No
Radiation Damper Available No
Room Side Installation Yes
UL Listed for use over bathtubs or showers when connected to a GFCI circuit Yes
Heater Wattage 0
Recommended Room Size (Sq Ft) 65
Rated Amps 0.3
Voltage 120
Can Be Used To Comply With Title 24 No
Minimum Construction Space Required 2" x 6"
Manufacturer Warranty 1 year
High Efficiency Luminaire No
